POWERTRAINS
2x 160 kW / 13.000 Nm on wheels
336-504 kWh NMC battery
300-480 km range
350 kW CCS Fast Charge
For buses from 10 t to 18 t - 800V System
INTERFACE
- The 7′′ Touchscreen is unified seamlessly into original front panel.
- Drivers can see energy efficiency, driving modes, climate system.
CLIMATE
Automatic climate control is integrated with a 7 kW electric heater and 5 kW efficient high voltage powered A/C unit.
Technical data
| Motor Type | EPM.32.80.A.HS-MDG |
Capacity/ Voltage |
720 – 800 V DC |
| Drive Type | Motor + Gearbox | Charger Power | MTA 22.0 kW / 44.0 kW Optional * |
| Efficiency | 94.5 % | Fast charge (CCS) power | 350 kW DC |
| Cooling | 50/50 water-glycol | Charging time | 7 - 8 hours |
| System Weight | 178 kg | Fast charging time (CCS) | < 1 hour |
| Battery Weight | 1200 kg / 1960 kg / 2400 kg |
